Inconel 625 Casting
Our Expertise of Inconel 625 Vacuum Precision Casting:
We are very experienced in Inconel 625 vacuum precision casting. With strong capability of casting a wide variety of Inconel super alloy, we provide custom Inconel super alloy casting parts and components for industries and applications including saltwater, aerospace and chemical processing applications and others. We can assure you high quality Inconel 625 vacuum precision casting part. The sizes of the casting parts range up to 32 inches. The weights of the vacuum casting parts are from 0.02 to 220 pounds. Typical casting tolerances meet ISO 8062 CT7 to CT5/ VDG P690 D1 to D2.
We work with our customers to assure that the Inconel 625 vacuum precision casting products/components can be manufactured with the desired characteristics in the most cost effective manner. Using simulation software to provide a “virtual prototype” we can begin to optimize the design prior to supplying products/components for design validation. We strive to be our customers’ best Inconel 625 vacuum precision casting supply chain partner.
For your Inconel 625 vacuum precision casting, we can help you out.
An Introduction to Inconel 625:
Inconel 625 castings are regularly used in saltwater, aerospace and chemical processing applications. Inconel 625 castings provide excellent resistance to seawater and chloride stress corrosion cracking. Inconel 625 castings contain a relatively high level of molybdenum which provides excellent high temperature strength up to approximately 1800°F (982°C) including high fatigue strength and high creep strength. Inconel 625 castings can be welded without pre or post heat treatment. Inconel 625 is also known as CW6MC, 60Ni-22Cr-9Mo-3.5Cb and UNS N26625.
Why Vacuum Precision Cast Inconel 625?
Hardness, toughness and high temperature strength make nickel-based super alloys extremely difficult to machine. Vacuum precision casting avoids this problem by producing accurate parts that are near-net shape. While the processes used for making wax patterns and ceramic cores are complicated, vacuum precision casting need little final machining. This makes vacuum precision casting cost-effective for more complex parts required in higher volumes.
In the early days of super alloys, parts were forged rather than cast. However, the development of vacuum precision casting eliminated the porosity problems that plagued early attempts at casting. Today almost all investment casting of super alloys is performed under vacuum.
Material Information of Nickel-Based Super Alloy Inconel 625 (IN625)
The most prominence of nickel-based super alloy Inconel 625 is its exceptional corrosion resistance and high temperature resistance. Inconel 625 are typically used in high temperature applications. Common trade names:
- Inconel Alloy 625 include: Inconel 625, Chronin 625, Altemp 625, Haynes 625, Nickelvac 625 and Nicrofer 6020
|Applications of Nickel-Based Super Alloy Inconel 625 (IN625)|
|Industries:||Inconel 625 castings are regularly used in saltwater, aerospace and chemical processing applications|
|Characteristic:||Inconel 625 castings provide excellent resistance to seawater and chloride stress corrosion cracking. Inconel 625 castings contain a relatively high level of molybdenum which provides excellent high temperature strength up to approximately 1800°F (982°C) including high fatigue strength and high creep strength. Inconel 625 castings can be welded without pre or post heat treatment. Inconel 625 is also known as CW6MC, 60Ni-22Cr-9Mo-3.5Cb and UNS N26625|
|Chemical Composition of Nickel-Based Super Alloy Inconel 625 (IN625)|
|20.0-23.0||3.15-4.15||0.4 Max||8.0-10.0||0.4 Max|
|0.1 Max||1.00 Max||5 Max||0.5 Max||0.5 Max|
|Mechanical Properties of Nickel-Based Super Alloy Inconel 625 (IN625)|
|Density||Tensile Strength, Ultimate||Tensile Strength, Yield||Elongation at Break|
|0.305 lb/in³||110,000 psi @ 1,200°F||42,100 psi @ 1,200°F||55% @ 1,200°|
